The DIP Flyback IC is a single-output device with a maximum supply current of 1.9mA and a power dissipation of 1.7W. It is designed for operation over a temperature range of -20°C to 85°C and is compliant with RoHS regulations. The IC is packaged in a DIP package and is available in quantities of 1000. It is suitable for use in through-hole mounting applications and is lead-free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP SSL1623PH/N1,112 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
NXP SSL1623PH/N1,112 technical specifications.
| Package/Case | DIP |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Max Supply Current | 1.9mA |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Package Quantity | 1000 |
| Packaging | Rail/Tube |
| Power Dissipation | 1.7W |
| RoHS Compliant | Yes |
| Topology | Flyback |
| RoHS | Compliant |
Download the complete datasheet for NXP SSL1623PH/N1,112 to view detailed technical specifications.
