The TJA1059TKJ is a dual transceiver IC designed for high-speed data transfer. It operates over a temperature range of -40°C to 150°C and is powered by a supply voltage between 4.75V and 5.25V. The device is packaged in the HVSON package and is suitable for surface mount applications. The transceiver features a data rate of 1Mbps and is compliant with RoHS regulations. It is not Reach SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP TJA1059TKJ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | HVSON |
| Data Rate | 1Mbps |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.25V |
| Min Supply Voltage | 4.75V |
| Mount | Surface Mount |
| Number of Transceivers | 2 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| Receiver Hysteresis | 300mV |
| RoHS Compliant | Yes |
| Simplex/Duplex | Half Duplex |
| RoHS | Compliant |
Download the complete datasheet for NXP TJA1059TKJ to view detailed technical specifications.
