Omron
A16-TBM-1
Switch Push Button N.O./N.C. SPDT Round Button 5A 250VAC 30VDC Momentary Contact Panel Mount Solder
Current Rating5A
MountingPanel, Front
Quick Jump:
Technical Specifications
Omron A16-TBM-1 technical specifications.
General
Actuator Type
Round, Button
Body Material
Resin, Polycarbonate
Contact Current Rating
3A
Current Rating
5A
Diameter
18mm
Electrical Life
100000Cycles
Lead Free
Lead Free
Max Operating Temperature
55°C
Mechanical Life
2000000Cycles
Min Operating Temperature
-10°C
Mount
Panel, Front
Orientation
Vertical
Package Quantity
1
Packaging
Bulk
Ratings
IP40
RoHS Compliant
Yes
Series
A16
Switch Function
On-Mom
Termination
Solder
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
30V
Compliance
RoHS
Compliant
Datasheet
Omron A16-TBM-1 Datasheet
Download the complete datasheet for Omron A16-TBM-1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
