Rotary DIP switch with 16 positions (SP16T) and flush screwdriver actuator. Features PC pin termination with a 2.54mm terminal pitch, suitable for through-hole mounting. Offers a contact current rating of 100mA at 28VDC, with a mechanical life of 10,000 cycles and electrical life of 2,000 cycles. Operates within a temperature range of -10°C to 70°C. This washable, lead-free, and RoHS-compliant component is packaged in trays.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron A6A-16CF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron A6A-16CF technical specifications.
| Actuator Length | 0mm |
| Actuator Type | Rotary |
| Package/Case | DIP |
| Color | Black |
| Contact Current Rating | 100mA |
| Current Rating | 100mA |
| Electrical Life | 2000Cycles |
| Lead Free | Lead Free |
| Length | 0.393inch |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 28V |
| Mechanical Life | 10000Cycles |
| Min Operating Temperature | -10°C |
| Mount | Through Hole |
| Number of Positions | 16 |
| Orientation | Straight |
| Package Quantity | 100 |
| Packaging | Tray |
| Pitch | 0.1inch |
| Radiation Hardening | No |
| Reach SVHC Compliant | Yes |
| RoHS Compliant | Yes |
| Series | A6A |
| Switching Voltage | 28V |
| Terminal Pitch | 2.54mm |
| Termination | PC Pins |
| Throw Configuration | SP16T |
| DC Rated Voltage | 28V |
| Washable | Yes |
| Weight | 0.7g |
| RoHS | Compliant |
