This Omron A6S-8102-PMH is an 8-position rotary slide actuator switch with a maximum operating temperature of 70°C and a minimum operating temperature of -20°C. It has a current rating of 25mA and a maximum voltage rating of 24V DC. The switch is surface mount and has a pitch of 0.1inch. It is RoHS compliant and has a mechanical life of 1000 cycles. The switch is also washable and has an electrical life of 1000 cycles.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron A6S-8102-PMH datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Slide (Standard) |
| Contact Plating | Gold |
| Current Rating | 25mA |
| Electrical Life | 1000Cycles |
| Length | 0.837inch |
| Life (Hours) | 1000Hour |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -20°C |
| Max Voltage Rating (DC) | 24V |
| Mechanical Life | 1000Cycles |
| Mount | Surface Mount |
| Number of Positions | 8 |
| Packaging | Tape and Reel |
| Pitch | 0.1inch |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | A6S-H |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| DC Rated Voltage | 24V |
| Washable | Yes |
| RoHS | Compliant |
