4-position, 4-pole rotary DIP switch featuring a piano actuator with a 0.9mm length. This surface mount component offers gold-plated contacts for a 25mA contact current rating at 24V DC. Designed for straight orientation with gull wing termination and a 2.54mm terminal pitch, it boasts a mechanical and electrical life of 1000 cycles. Operating within a temperature range of -20°C to 70°C, this RoHS compliant switch is packaged in rails/tubes.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron A6SR-4104 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Length | 0.9mm |
| Actuator Type | PIANO |
| Contact Current Rating | 25mA |
| Contact Material | Gold |
| Contact Plating | Gold |
| Current Rating | 25mA |
| Electrical Life | 1000Cycles |
| Height | 5mm |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 24V |
| Mechanical Life | 1000Cycles |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Poles | 4 |
| Number of Positions | 4 |
| Orientation | Straight |
| Package Quantity | 47 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | A6SR |
| Terminal Pitch | 2.54mm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| DC Rated Voltage | 24V |
| Washable | No |
| Weight | 0.48g |
| Width | 9.8mm |
| RoHS | Compliant |
