The Omron C2U-15 is a round button switch with a current rating of 2A and a voltage rating of 125V AC or 30V DC. It has a maximum operating temperature of 40°C and a minimum operating temperature of -10°C. The switch features a mechanical life of 500,000 cycles and an electrical life of 200,000 cycles. It is available in a bulk packaging with 10 units per package and has wire leads for termination.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron C2U-15 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Round, Button |
| Current Rating | 2A |
| Electrical Life | 200000Cycles |
| Max Operating Temperature | 40°C |
| Mechanical Life | 500000Cycles |
| Min Operating Temperature | -10°C |
| Mount | Free Hanging |
| Operating Force | 0.5N |
| Package Quantity | 10 |
| Packaging | Bulk |
| Series | C2U |
| Switch Function | Off-Mom |
| Termination | Wire Leads |
| Throw Configuration | DPST |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| RoHS | Compliant |
Download the complete datasheet for Omron C2U-15 to view detailed technical specifications.
