SPDT snap action switch featuring a 100mA current rating at 125VAC and 30VDC. Constructed with gold contacts and a stainless steel/polyacetal lever actuator, this switch offers a 0.59N operating force. It boasts an electrical life of 200,000 cycles and a mechanical life of 5,000,000 cycles. Rated IP67 for waterproof and dust-tight protection, it supports panel, chassis, screw, and wire mounting with straight wire lead termination.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron D2SW-01L2MS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Material | Stainless Steel, Polyacetal |
| Actuator Type | Lever |
| Approvals | UL, CSA, IEC |
| Package/Case | 100 |
| Contact Current Rating | 1mA |
| Contact Material | Gold |
| Current Rating | 100mA |
| Depth | 6.4mm |
| Electrical Life | 200000Cycles |
| Lead Free | Lead Free |
| Length | 22.75mm |
| Max Current Rating | 100mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 5000000Cycles |
| Mount | Panel, Chassis Mount, Screw, Wire |
| Number of Poles | 1 |
| Operating Force | 0.59N |
| Orientation | Straight |
| Package Quantity | 20 |
| Packaging | Tray |
| Radiation Hardening | No |
| Ratings | IP67, Waterproof, Dust Tight |
| RoHS Compliant | Yes |
| Series | D2SW |
| Switch Function | On-Mom |
| Termination | Wire Leads |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| Weight | 10g |
| RoHS | Compliant |
