Omron
D2VW-01L3-1
OMRON ELECTRONIC COMPONENTS D2VW-01L3-1 Microswitch, SPDT, Simulated Roller Lever, Solder, 100 mA, 125 VAC
Package100
Current Rating100mA
MountingSolder
Quick Jump:
Technical Specifications
Omron D2VW-01L3-1 technical specifications.
General
Actuator Type
SIMULATED ROLLER LEVER
Package/Case
100
Contact Current Rating
100mA
Contact Material
Gold
Contact Plating
Gold
Current Rating
100mA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Solder
Operating Force
1.18N
Ratings
IP67
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Termination
Solder
Throw Configuration
SPDT
Compliance
RoHS
Compliant
Datasheet
Omron D2VW-01L3-1 Datasheet
Download the complete datasheet for Omron D2VW-01L3-1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
