SPDT snap action switch with a hinge lever, featuring quick connect terminals and screw mounting for panel or chassis installation. Offers a 16A current rating at 250VAC and 250VDC, with a 372.85VA rating. Silver contacts ensure reliable performance with an electrical life of 100,000 cycles and a mechanical life of 10,000,000 cycles. Operating force is 2N, with a pretravel of 0.157 inches and overtravel of 0.062 inches. Rated for operation between -25°C and 105°C, with IP40/IP00 ratings.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron D3V-16G2M-1C25-K datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Contact Material | Silver |
| Current Rating | 10A |
| Differential Travel | 0.031inch |
| Electrical Life | 100000Cycles |
| Height | 18.7mm |
| Lead Free | Lead Free |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 250V |
| Mechanical Life | 10000000Cycles |
| Mount | Panel, Chassis Mount, Screw |
| Number of Poles | 1 |
| Operating Force | 2N |
| Operating Position | 0.6inch |
| Orientation | Straight |
| Overtravel | 0.062inch |
| Package Quantity | 100 |
| Packaging | Bulk |
| Pretravel | 0.157inch |
| Ratings | IP40, IP00 |
| Series | D3V |
| Switch Function | On-Mom |
| Termination | Quick Connect |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 30V |
| Width | 27.8mm |
| RoHS | Compliant |
