SPDT limit switch featuring a roller lever actuator. Rated for 5A at 125VAC and 250VDC, with a 30VDC rating. Offers a mechanical life of 10,000,000 cycles and an electrical life of 500,000 cycles. Designed with screw termination and chassis mounting, it operates within a temperature range of -10°C to 80°C. IP67, waterproof, and dust-tight ratings ensure robust performance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron D4E-1A20N datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron D4E-1A20N technical specifications.
| Package/Case | 125 |
| Current Rating | 5A |
| Differential Travel | 0.004inch |
| Electrical Life | 500000Cycles |
| Max Operating Temperature | 80°C |
| Mechanical Life | 10000000Cycles |
| Min Operating Temperature | -10°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 250V |
| Mount | Screw, Chassis Mount |
| Operating Force | 11.77N |
| Operating Position | 1.235inch |
| Orientation | Straight |
| Overtravel | 0.118inch |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pretravel | 0.06inch |
| Ratings | IP67, Waterproof, Dust Tight |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | D4E-xN |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| RoHS | Compliant |
