The Omron D4N-212G is a DPDT DPST rotary switch with a current rating of 2.5A and a voltage rating of 120V AC. It features a screw mount and is rated for operation in temperatures between -30°C and 70°C. The switch has a mechanical life of 15 million cycles and an electrical life of 300,000 cycles. It is compliant with RoHS regulations and has an IP67 rating for waterproof and dust-tight operation.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron D4N-212G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Rotary |
| Current Rating | 2.5A |
| Electrical Life | 300000Cycles |
| Max Operating Temperature | 70°C |
| Mechanical Life | 15000000Cycles |
| Min Operating Temperature | -30°C |
| Mount | Screw, Chassis Mount |
| Operating Force | 6.5N |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67, Waterproof, Dust Tight |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | D4N |
| Termination | Screw |
| Throw Configuration | DPDT, DPST |
| Voltage Rating (AC) | 120V |
| DC Rated Voltage | 125V |
| RoHS | Compliant |
