DPST Limit Switch with Roller Lever actuator. Features a 240V AC, 10A and 250V DC, 2.5A rating. Offers 2 contacts, screw termination, and a mechanical life of 15,000,000 cycles. IP67 rated for waterproof and dust-tight operation, with an operating force of 510gf. Dimensions are 92mm length, 31mm width, and 30mm depth.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron D4N-2162 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | ROLLER LEVER |
| Current Rating | 2.5A |
| Depth | 30mm |
| Differential Travel | 0.06inch |
| Electrical Life | 300000Cycles |
| Length | 92mm |
| Max Operating Temperature | 70°C |
| Mechanical Life | 15000000Cycles |
| Min Operating Temperature | -30°C |
| Mount | Chassis Mount |
| Number of Contacts | 2 |
| Operating Force | 510gf |
| Operating Position | 1.457inch |
| Overtravel | 0.197inch |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pretravel | 0.157inch |
| Ratings | IP67, Waterproof, Dust Tight |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | D4N |
| Termination | Screw |
| Throw Configuration | DPST |
| Voltage Rating (AC) | 240V |
| DC Rated Voltage | 250V |
| Width | 31mm |
| RoHS | Compliant |
