Inductive proximity sensor with a 2mm sensing distance and NPN output configuration. Features a stainless steel body, 15mm diameter, and operates within a 10V to 40V supply voltage range. Rated IP67 for environmental protection and offers a response frequency of 800Hz. Suitable for mounting via brackets, DIN rail, or panel, with a connector termination. Compliant with UL approvals and RoHS standards.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron E2E-X2ME1-M1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL |
| Body Material | Stainless Steel |
| Diameter | 15mm |
| Height | 15mm |
| Length | 37mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 40V |
| Min Supply Voltage | 10V |
| Mount | Brackets, DIN Rail, Panel |
| Operating Supply Voltage | 30V |
| Output Configuration | NPN |
| Output Type | NPN |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67 |
| Response Frequency | 800Hz |
| RoHS Compliant | Yes |
| Sensing Distance | 2mm |
| Sensing Method | Inductive |
| Series | E2E |
| Shielding | Unshielded |
| Termination | Connector |
| Width | 15mm |
| RoHS | Compliant |
Download the complete datasheet for Omron E2E-X2ME1-M1 to view detailed technical specifications.
