Shielded inductive proximity sensor with a sensing distance of 0.5mm. Features a brass body, panel mount, and cable lead termination. Operates with a supply voltage range of 4.75V to 30V, a switching current of 100mA, and a PNP output type. Rated IP64 for environmental protection, with an operating temperature range of -25°C to 70°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron E2EC-CR5B1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Body Material | Brass |
| Depth | 5mm |
| Height | 5mm |
| Length | 447mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 4.75V |
| Mount | Panel |
| Operating Supply Voltage | 24V |
| Output Type | PNP |
| Package Quantity | 1 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ratings | IP64 |
| Response Frequency | 1kHz |
| RoHS Compliant | No |
| Sensing Distance | 0.5mm |
| Sensing Method | Inductive |
| Series | E2E |
| Shielding | Shielded |
| Switching Current | 100mA |
| Termination | Cable Leads |
| Width | 10mm |
| RoHS | Not CompliantNo |
