Inductive proximity sensor with a sensing distance of 0.8mm. Features a brass body, panel mount, and shielded design. Operates within a DC supply voltage range of 10V to 30V, with a nominal supply current of 13mA. Rated IP67 for environmental protection and operates between -25°C and 70°C. Includes cable leads for termination and offers a response frequency of 1.5kHz.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron E2EC-CR8D1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Body Material | Brass |
| Height | 10.7mm |
| Length | 459mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage (DC) | 30V |
| Min Supply Voltage (DC) | 10V |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 10V |
| Mount | Panel |
| Nominal Supply Current | 13mA |
| Operating Supply Voltage | 24V |
| Package Quantity | 1 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Response Frequency | 1.5kHz |
| RoHS Compliant | Yes |
| Sensing Distance | 0.8mm |
| Sensing Method | Inductive |
| Series | E2E |
| Shielding | Shielded |
| Termination | Cable Leads |
| Width | 8mm |
| RoHS | Compliant |
Download the complete datasheet for Omron E2EC-CR8D1 to view detailed technical specifications.
