The E3ZM-D87 is a PNP output amplifier with a dark-on configuration, suitable for operation at 24V with a maximum output current of 100mA. It features a metal package and is rated for a maximum operating temperature of 55°C and a minimum operating temperature of -25°C. The device is RoHS compliant and has an IP67 and IP69K rating, indicating its resistance to dust and water ingress. It has a response time of 1ms and a sensing distance of 39.37 inches, utilizing an optical sensing method.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron E3ZM-D87 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron E3ZM-D87 technical specifications.
| Package/Case | Metal |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage (DC) | 30V |
| Min Supply Voltage (DC) | 10V |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 10V |
| Mount | Screw |
| Operating Supply Voltage | 24V |
| Output Configuration | Dark-On |
| Output Current | 100mA |
| Output Type | PNP |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67, IP69K |
| Reach SVHC Compliant | No |
| Response Time | 1ms |
| RoHS Compliant | Yes |
| Sensing Distance | 39.37inch |
| Sensing Method | Optical |
| Series | E3ZM |
| RoHS | Compliant |
Download the complete datasheet for Omron E3ZM-D87 to view detailed technical specifications.
