Technical Specifications
Omron EE-SPX402-W2A technical specifications.
General
Height
13mm
Lead Free
Contains Lead
Length
21.2mm
Max Collector Current
50mA
Max Operating Temperature
55°C
Min Operating Temperature
-10°C
Max Supply Voltage
24V
Min Supply Voltage
5V
Mount
Chassis Mount, Screw
Output Configuration
NPN - Open Collector
Output Type
Phototransistor, NPN
Package Quantity
1
Ratings
IP50
RoHS Compliant
Yes
Sensing Distance
3.6mm
Sensing Method
Optical
Termination
Cable
Wavelength
940nm
Width
15.5mm
Compliance
RoHS
Compliant
Datasheet
Omron EE-SPX402-W2A Datasheet
Download the complete datasheet for Omron EE-SPX402-W2A to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
