The Omron G2R-2-AUL-T130DC24 is a general purpose DPDT relay with a non-latching coil type, rated for 24V DC and 530mW power. It features a silver contact material and a current rating of 5A. The relay operates within a temperature range of -40°C to 70°C and has a through hole mount. It is available in a tray packaging and has a termination type of PC Pin.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G2R-2-AUL-T130DC24 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Coil Current | 21.8mA |
| Coil Power | 530mW |
| Coil Resistance | 1.1kR |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24V |
| Contact Current Rating | 5A |
| Contact Material | Silver |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Operate Time | 15ms |
| Packaging | Tray |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Series | G2R |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| RoHS | Compliant |
