The Omron G3M-203PDC24 is a solid state relay with a maximum operating temperature of 80°C and a minimum operating temperature of -30°C. It has a maximum output voltage of 264V and a maximum output current of 3A. The relay is packaged in a SIP case and is mounted through a hole on a PCB. It has a turn-on delay time of 1ms and is not RoHS compliant.
Checking distributor stock and pricing after the page loads.
Omron G3M-203PDC24 technical specifications.
| Package/Case | SIP |
| Depth | 9mm |
| Height | 20mm |
| Input Type | DC |
| Lead Free | Lead Free |
| Length | 40mm |
| Load Current | 3A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 3A |
| Max Output Voltage | 264V |
| Mount | Through Hole, PCB |
| Package Quantity | 1 |
| Packaging | Bulk |
| Relay Type | Relay |
| RoHS Compliant | No |
| Series | G3M |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Turn-On Delay Time | 1ms |
| RoHS | Not Compliant |
No datasheet is available for this part.
