Solid State Relay (SSR) with SPST-NO configuration, rated for 1A load current and up to 132V AC output. Features DC input, 2.5kV isolation voltage, and operates within a -30°C to 80°C temperature range. Mounts via through-hole or PCB with solder termination. Approvals include UL, CSA, and VDE.
PackageSIP
Current Rating1A
MountingThrough Hole, PCB
Quick Jump:
Technical Specifications
Omron G3MC101PDC12 technical specifications.
General
Approvals
UL, CSA, VDE
Package/Case
SIP
Current Rating
1A
Depth
4.5mm
Height
13.5mm
Input Type
DC
Isolation Voltage
2.5kV
Lead Free
Lead Free
Length
24.5mm
Load Current
1A
Max Operating Temperature
80°C
Min Operating Temperature
-30°C
Max Output Current
1A
Max Output Voltage
132V
Mount
Through Hole, PCB
Output Current
1A
Package Quantity
1
Packaging
Bulk
Radiation Hardening
No
Series
G3MC
Termination
Solder
Throw Configuration
SPST
Turn-On Delay Time
1ms
Voltage Rating (AC)
120V
Width
4.5mm
Compliance
RoHS
Compliant
Datasheet
Omron G3MC101PDC12 Datasheet
Download the complete datasheet for Omron G3MC101PDC12 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
