Technical Specifications
Omron G3VM-SY technical specifications.
General
Package/Case
SOP
Height
2.1mm
Input Current
50mA
Input Type
DC
Isolation Voltage
1.5kV
Lead Free
Lead Free
Length
9.4mm
Load Current
300mA
Max Input Voltage
1.3V
Max Operating Temperature
85°C
Min Operating Temperature
-20°C
Max Output Current
200mA
Max Output Voltage
60V
Mount
Surface Mount
Output Current
200mA
Output Voltage
60V
Package Quantity
50
Packaging
Rail/Tube
Radiation Hardening
No
Series
G3VM
Termination
Gull Wing
Throw Configuration
DPST, SPST
Width
4.4mm
Compliance
RoHS
Compliant
Datasheet
Omron G3VM-SY Datasheet
Download the complete datasheet for Omron G3VM-SY to view detailed technical specifications.
