SPDT PCB power relay featuring a 24VDC coil with 400mW power consumption and 16.7mA coil current. This general-purpose relay offers a 10A switching current and 277VAC/30VDC voltage rating with silver contact material. Designed for PCB mounting with PC pin termination, it boasts a 10 million operation life and operates within a -40°C to 85°C temperature range. The relay is rated IP67 and is REACH SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G5Q-1-EU24DC datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron G5Q-1-EU24DC technical specifications.
| Application(s) | POWER |
| Coil Current | 16.7mA |
| Coil Power | 400mW |
| Coil Resistance | 1.44kR |
| Coil Voltage (DC) | 24V |
| Contact Material | Silver |
| Contact Type | 1 change-over |
| Current Rating | 16.7mA |
| Depth | 10.3mm |
| Height | 16.2mm |
| Length | 20.3mm |
| Life (Hours) | 10000000Hour |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | PCB |
| Operate Time | 10ms |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Yes |
| Switching Current | 10A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 277V |
| DC Rated Voltage | 30V |
| Width | 10.3mm |
| RoHS | Compliant |
