| Package/Case | DIP |
| Coil Current | 28.3mA |
| Coil Power | 750mW |
| Coil Resistance | 443R |
| Coil Voltage (AC) | 24V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Cadmium |
| Height | 15.5mm |
| Lead Free | Lead Free |
| Length | 28.8mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 24V |
| Mount | Through Hole |
| Operate Time | 20ms |
| Packaging | Rail/Tube |
| Power Consumption | 750mW |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Weight | 10g |
| Width | 12.5mm |
| RoHS | Compliant |
