The Omron G6B-2214P-FD-US-DC24 is a DPST relay with a 24V DC coil and a maximum current rating of 5A. It has a maximum voltage rating of 125V and can operate in temperatures ranging from -25°C to 70°C. The relay is packaged in a DIP format and is mounted through a hole. It features a tin and silver contact material and a solder termination.
Checking distributor stock and pricing after the page loads.
| Package/Case | DIP |
| Coil Current | 12.5mA |
| Coil Resistance | 1.92kR |
| Coil Voltage (DC) | 24V |
| Contact Material | Tin, Silver |
| Max Current Rating | 5A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (AC) | 380V |
| Max Voltage Rating (DC) | 125V |
| Mount | Through Hole |
| Operate Time | 10ms |
| Termination | Solder |
| Throw Configuration | DPST |
| Weight | 4.5g |
| RoHS | Compliant |
