SPDT signal relay with a 9VDC non-latching coil, featuring a 2A contact current rating and a 3A maximum current rating. This through-hole mounted component offers gold and silver contact material, operates within a -40°C to 70°C temperature range, and has a 250VAC/220VDC maximum voltage rating. It boasts a 5ms operate and release time, with a coil power of 200mW and a coil resistance of 405 ohms.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G6E-134P-ST-US-DC9 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron G6E-134P-ST-US-DC9 technical specifications.
| Coil Current | 22.2mA |
| Coil Power | 200mW |
| Coil Resistance | 405R |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 9V |
| Contact Current Rating | 2A |
| Contact Material | Gold, Silver |
| Height | 8mm |
| Lead Free | Lead Free |
| Max Current Rating | 3A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 220V |
| Mount | Through Hole |
| Operate Time | 5ms |
| Package Quantity | 25 |
| Packaging | Bulk |
| Power Consumption | 200mW |
| Radiation Hardening | No |
| Relay Type | General Purpose |
| Release Time | 5ms |
| RoHS Compliant | Yes |
| Series | G6E |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Weight | 2.7g |
| Width | 10mm |
| RoHS | Compliant |
