The Omron G6K-2F-YDC6 is a telecom relay with a DPDT throw configuration, rated for 60V and 1A. It has a non-latching coil with a resistance of 341 ohms and a current of 17.6mA at 6V DC. The relay operates within a temperature range of -40°C to 70°C and consumes 100mW of power. It is available in a surface mount package with a gull wing termination and is lead free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G6K-2F-YDC6 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Coil Current | 17.6mA |
| Coil Resistance | 341R |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 6V |
| Contact Current Rating | 1A |
| Contact Material | Gold, Silver |
| Lead Free | Lead Free |
| Max Current Rating | 1A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 60V |
| Mount | Surface Mount |
| Operate Time | 3ms |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Consumption | 100mW |
| Radiation Hardening | No |
| Relay Type | Telecom |
| Release Time | 3ms |
| Series | G6K |
| Termination | Gull Wing |
| Throw Configuration | DPDT |
| RoHS | Compliant |
