The MKS2XTIN-11DC48 is a general purpose relay from Omron with a non-latching coil type and a maximum operating temperature of 60°C. It has a contact current rating of 5A and a contact material of tin and silver. The relay is socketable and has a package quantity of one, packaged in bulk. It is compliant with RoHS regulations and has a series designation of MKS-X.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron MKS2XTIN-11DC48 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Coil Current | 32mA |
| Coil Power | 1.5W |
| Coil Resistance | 1.5kR |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 48V |
| Contact Current Rating | 5A |
| Contact Material | Tin, Silver |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Mount | Socketable |
| Operate Time | 30ms |
| Package Quantity | 1 |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Release Time | 20ms |
| RoHS Compliant | Yes |
| Series | MKS-X |
| Termination | Plug |
| Throw Configuration | DPST |
| RoHS | Compliant |
Download the complete datasheet for Omron MKS2XTIN-11DC48 to view detailed technical specifications.
