Single output DC/DC converter, 7.5W, delivering 5V at 1.5A. Features include a 12-24V DC input range, 74% efficiency, and a module package suitable for DIN rail mounting. Operating temperature range is -10°C to 60°C. Approvals include UL, CSA, VDE, and CE, with RoHS compliance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron S82S-7705 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, VDE, CE |
| Package/Case | Module |
| Current - Output 1 | 1.5A |
| Depth | 37.5mm |
| Efficiency | 74% |
| Height | 2.95inch |
| Length | 65mm |
| Max Input Voltage (DC) | 24V |
| Min Input Voltage (DC) | 12V |
| Max Input Voltage | 27.6V |
| Min Input Voltage | 10.2V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -10°C |
| Max Output Power | 7.5W |
| Max Output Voltage | 5V |
| Min Output Voltage | 5V |
| Max Power Dissipation | 7W |
| Mount | DIN Rail |
| Number of Outputs | 1 |
| Output | 5V |
| Output Current | 1.5A |
| Output Power | 7.5W |
| Output Voltage | 5V |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | S82S |
| Voltage - Output 1 | 5V |
| Weight | 150g |
| Width | 75mm |
| RoHS | Not Compliant |
