150W AC/DC converter with a single 5V output, delivering up to 27A. Features include 85-264V AC input range, 50-60Hz frequency, 3kV isolation voltage, and 81% efficiency. Operates from -10°C to 70°C and is DIN rail mountable. Approvals include VDE, CE, cULus, and cURus.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron S8VM15005CD datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Omron S8VM15005CD technical specifications.
| Approvals | VDE, CE, cULus, cURus |
| Current - Output 1 | 27A |
| Depth | 84.5mm |
| Efficiency | 81% |
| Height | 84.5mm |
| Isolation Voltage | 3kV |
| Lead Free | Lead Free |
| Length | 164.5mm |
| Max Frequency | 60Hz |
| Min Frequency | 50Hz |
| Max Input Voltage (AC) | 240V |
| Min Input Voltage (AC) | 85V |
| Max Input Voltage | 264V |
| Min Input Voltage | 85V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -10°C |
| Max Output Current | 27A |
| Max Output Power | 150W |
| Max Output Voltage | 5V |
| Min Output Voltage | 5V |
| Max Power Dissipation | 150W |
| Max Supply Voltage | 240V |
| Min Supply Voltage | 100V |
| Mount | DIN Rail |
| Nominal Output Voltage | 5V |
| Number of Outputs | 1 |
| Output Current | 27A |
| Output Power | 150W |
| Output Voltage | 5V |
| Package Quantity | 1 |
| Reach SVHC Compliant | No |
| Series | S8VM |
| Voltage - Output 1 | 5V |
| Weight | 1.168lb |
| Width | 44mm |
| RoHS | Compliant |
