OMRON

SS-01-FD

Datasheet

Subminiature SPDT Snap Action Switch, 100mA, 125VAC, Pin Plunger, PC Pin

Omron

SS-01-FD

Name: SS-01-FD Omron
Brand: Omron
SKU: SS-01-FD

Subminiature SPDT Snap Action Switch, 100mA, 125VAC, Pin Plunger, PC Pin

Subminiature basic switch featuring a pin plunger actuator and SPDT throw configuration. Rated for 100mA at 125VAC and 30VDC, with gold contact material for reliable performance. Offers a mechanical life of 30,000,000 cycles and an electrical life of 200,000 cycles. Mounts via through-hole or screw, with PC pin termination. Operating force is 0.49N, and it operates within a temperature range of -25°C to 85°C.

Current Rating100mA

MountingThrough Hole, Screw

Quick Jump:

Technical Specifications

Omron SS-01-FD technical specifications.

General

Actuator Type	PIN PLUNGER
Contact Current Rating	100mA
Contact Material	Gold
Current Rating	100mA
Electrical Life	200000Cycles
Lead Free	Lead Free
Max Operating Temperature	85°C
Min Operating Temperature	-25°C
Max Voltage Rating (AC)	125V
Max Voltage Rating (DC)	30V
Mechanical Life	30000000Cycles
Mount	Through Hole, Screw
Operating Force	0.49N
Orientation	Straight
Package Quantity	500
Packaging	Bulk
Radiation Hardening	No
Ratings	IP40
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Series	SS
Switch Function	On-Mom
Termination	PC Pin
Throw Configuration	SPDT
Voltage Rating (AC)	125V
DC Rated Voltage	30V
Weight	1.6g
