SPDT/SPST general purpose limit switch featuring snap-action contacts and a side rotary actuator with an adjustable roller lever. Rated for 10A at 500VAC and 250VDC, with a 125V AC and 30V DC rating. Offers a mechanical life of 15,000,000 cycles and an electrical life of 750,000 cycles. Constructed with stainless steel and aluminum, this IP67 waterproof and dust-tight switch mounts via screw terminals. Operating force is 13.34N (1360gf), with dimensions of 40mm (L) x 68.7mm (W) x 42mm (D) and an operating temperature range of -10°C to 80°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron WLCA12-TS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Rotary |
| Contact Type | Snap Action |
| Current Rating | 10A |
| Depth | 42mm |
| Electrical Life | 750000Cycles |
| Length | 40mm |
| Material | Stainless Steel, Aluminium |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -10°C |
| Max Voltage Rating (AC) | 500V |
| Max Voltage Rating (DC) | 250V |
| Mechanical Life | 15000000Cycles |
| Mount | Chassis Mount, Screw |
| Operating Force | 1360gf |
| Orientation | Right Angle |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67, Waterproof, Dust Tight |
| Reach SVHC Compliant | Unknown |
| Series | WL |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT, SPST, DPST |
| Type | General Purpose |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| Width | 68.7mm |
| RoHS | Not Compliant |
