The Omron ZC-N2255-MLVCT1M is a basic and snap action switch with a SPDT throw configuration and on-mom switch function. It has a current rating of 6A and a voltage rating of 125V AC and 30V DC. The switch is designed for chassis mount and has an operating force of 700gf. It is rated for 500,000 electrical cycles and 10,000,000 mechanical cycles. The switch is packaged in bulk and is rated for IP67, waterproof, and dust tight.
Checking distributor stock and pricing after the page loads.
| Current Rating | 6A |
| Electrical Life | 500000Cycles |
| Max Operating Temperature | 80°C |
| Mechanical Life | 10000000Cycles |
| Min Operating Temperature | -10°C |
| Mount | Chassis Mount |
| Operating Force | 700gf |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67, Waterproof, Dust Tight |
| Series | ZC |
| Switch Function | On-Mom |
| Termination | Cable Leads |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| RoHS | Compliant |
