The Omron ZC-Q2255-MRVCT5M is a basic and snap action switch with a SPDT throw configuration and on-mom switch function. It has a current rating of 6A and a DC rated voltage of 30V. The switch is rated for IP67, waterproof, and dust tight, and is designed for panel mount applications. It can operate in temperatures ranging from -10°C to 80°C and has a mechanical life of 10 million cycles.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron ZC-Q2255-MRVCT5M datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current Rating | 6A |
| Electrical Life | 500000Cycles |
| Max Operating Temperature | 80°C |
| Mechanical Life | 10000000Cycles |
| Min Operating Temperature | -10°C |
| Mount | Panel |
| Operating Force | 1200gf |
| Package Quantity | 1 |
| Packaging | Bulk |
| Ratings | IP67, Waterproof, Dust Tight |
| Series | ZC |
| Switch Function | On-Mom |
| Termination | Cable Leads |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| RoHS | Compliant |
