General purpose rectifier diode for small signal switching applications. Features a maximum repetitive reverse voltage of 75V and a reverse recovery time of 4ns. This single element diode offers an average rectified current of 200mA and a forward current of 300mA. Designed for surface mount with tin, matte contact plating, it operates within a temperature range of -55°C to 150°C. Packaged in tape and reel, this RoHS compliant component has a power dissipation of 200mW.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Onsemi 1N914BWT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Average Rectified Current | 200mA |
| Contact Plating | Tin, Matte |
| Element Configuration | Single |
| Forward Current | 300mA |
| Lead Free | Lead Free |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Repetitive Reverse Voltage (Vrrm) | 75V |
| Max Reverse Current | 5uA |
| Max Reverse Leakage Current | 5uA |
| Max Reverse Voltage (DC) | 75V |
| Mount | Surface Mount |
| Package Quantity | 8000 |
| Packaging | Tape and Reel |
| Power Dissipation | 200mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reverse Recovery Time | 4ns |
| Reverse Recovery Time-Max | 4ns |
| RoHS Compliant | Yes |
| Weight | 0.01g |
| RoHS | Compliant |
