Technical Specifications
Onsemi 74ACT520PC technical specifications.
General
| Package/Case | PDIP |
| High Level Output Current | 24mA |
| Lead Free | Lead Free |
| Low Level Output Current | 24mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Operating Supply Voltage | 5V |
| Package Quantity | 18 |
| Packaging | Rail/Tube |
| Polarity | Inverting |
| Propagation Delay | 10ns |
| Quiescent Current | 4uA |
| RoHS Compliant | Yes |
| Series | 74ACT |
| Technology | CMOS |
| Turn-On Delay Time | 11.5ns |
Compliance
| RoHS | Compliant |
Datasheet
Onsemi 74ACT520PC Datasheet
Download the complete datasheet for Onsemi 74ACT520PC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
