Single Zener Diode, 7.5V DC Rated Voltage, 5% Voltage Tolerance, 350mW Power Dissipation. Features 15 Ohms impedance and 140pF capacitance. Surface mountable in a 3-Pin SOT-23 package, measuring 2.92mm L x 1.3mm W x 0.93mm H. Operates from -55°C to 150°C, with a maximum reverse leakage current of 1uA. Packaged on tape and reel for 3000 units.
PackageSOT-23
Capacitance140pF
Voltage Rating7.5V
MountingSurface Mount
Quick Jump:
Technical Specifications
Onsemi BZX84C7V5 technical specifications.
General
| Capacitance | 140pF |
| Package/Case | SOT-23 |
| Height | 0.93mm |
| Impedance | 15R |
| Lead Free | Lead Free |
| Length | 2.92mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 350mW |
| Max Reverse Current | 1uA |
| Max Reverse Leakage Current | 1uA |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Power Dissipation | 350mW |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Tolerance | 6% |
| DC Rated Voltage | 7.5V |
| Voltage Tolerance | 5% |
| Weight | 0.03g |
| Width | 1.3mm |
| Working Voltage | 7.5V |
| Zener Current | 5mA |
| Zener Voltage | 7.5V |
Compliance
| RoHS | Compliant |
Datasheet
Onsemi BZX84C7V5 Datasheet
Download the complete datasheet for Onsemi BZX84C7V5 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
