The DM74LS138N is a single logic IC from Onsemi, packaged in a PDIP case for through-hole mounting. It operates within a temperature range of 0°C to 70°C and is supplied with a voltage between 4.75V and 5.25V. This device is not RoHS compliant and contains lead, making it a non-lead-free component.
PackagePDIP
MountingThrough Hole
Quick Jump:
Technical Specifications
Onsemi DM74LS138N technical specifications.
General
| Package/Case | PDIP |
| Independent Circuits | 1 |
| Lead Free | Contains Lead |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Voltage | 5.25V |
| Min Supply Voltage | 4.75V |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Packaging | Rail/Tube |
| RoHS Compliant | No |
| Series | 74LS |
| Supply Type | Single |
Compliance
| RoHS | Not Compliant |
Datasheet
Onsemi DM74LS138N Datasheet
Download the complete datasheet for Onsemi DM74LS138N to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
