The FAN1587AD15X is a surface mount fixed output regulator from Onsemi. It features a maximum operating temperature of 125°C and a minimum operating temperature of 0°C. The device has a maximum power dissipation of 18W and is RoHS compliant. It is available in a TO-252 package, packaged in tape and reel with 2500 units per reel.
Checking distributor stock and pricing after the page loads.
| Package/Case | TO-252 |
| Input Bias Current | 4mA |
| Lead Free | Lead Free |
| Max Input Voltage | 18V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 18W |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Current | 3A |
| Output Type | Fixed |
| Output Voltage | 1.5V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| RoHS | Compliant |
