FAN3225CMPX

5A Dual Low-Side Gate Driver, CMOS, 29ns PD, 9ns FT

Onsemi

FAN3225CMPX

Name: FAN3225CMPX Onsemi
Brand: Onsemi
SKU: FAN3225CMPX

5A Dual Low-Side Gate Driver, CMOS, 29ns PD, 9ns FT

Dual low-side gate driver IC featuring CMOS inputs and configurable inverting or non-inverting outputs. Delivers peak 5A sink and 5A source current with a 29ns propagation delay and 9ns fall time. Operates from a 4.5V to 18V supply voltage, with a maximum power dissipation of 540mW. Packaged as a surface mount module, this lead-free component is RoHS compliant and suitable for operation between -40°C and 125°C.

PackageModule

Current210uA

MountingSurface Mount

Quick Jump:

Technical Specifications

Onsemi FAN3225CMPX technical specifications.

General

Package/Case	Module
Fall Time	9ns
Height	0.75mm
Lead Free	Lead Free
Length	3mm
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
Max Output Current	5A
Max Power Dissipation	540mW
Max Supply Current	350uA
Max Supply Voltage	18V
Min Supply Voltage	4.5V
Mount	Surface Mount
Number of Drivers	2
Number of Outputs	2
Output Current	5A
Package Quantity	1
Packaging	Tape and Reel
Propagation Delay	29ns
Reach SVHC Compliant	No
RoHS Compliant	Yes
Supply Current	210uA
Weight	0.129g
Width	3mm
