600V, 15A motor driver IC featuring a PDIP package for through-hole mounting. This power management component offers a maximum collector current of 15A and a collector-emitter saturation voltage of 1.8V. Operating within a supply voltage range of 13.5V to 16.5V, it supports a maximum operating temperature of 150°C. The device is lead-free, RoHS compliant, and designed for efficient motion control applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Onsemi FNA41560B2 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | PDIP |
| Collector Emitter Saturation Voltage | 1.8V |
| Collector Emitter Voltage (VCEO) | 2.3V |
| Collector-emitter Voltage-Max | 600V |
| Current | 15A |
| Height | 4.8mm |
| Lead Free | Lead Free |
| Length | 39.5mm |
| Min Breakdown Voltage | 600V |
| Max Collector Current | 15A |
| Max Current Rating | 15A |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 41W |
| Max Supply Voltage | 16.5V |
| Min Supply Voltage | 13.5V |
| Mount | Through Hole |
| Package Quantity | 12 |
| Packaging | Rail/Tube |
| RoHS Compliant | Yes |
| Series | Motion SPM® 45 |
| Voltage | 600V |
| Weight | 17.088g |
| Width | 23.5mm |
| RoHS | Compliant |
Download the complete datasheet for Onsemi FNA41560B2 to view detailed technical specifications.
