The FSAM10SM60A is a 6-channel power module from Onsemi with a collector-emitter breakdown voltage of 450V and saturation voltage of 2.3V. It features a maximum operating temperature of 125°C and a minimum operating temperature of -20°C. The module is packaged in a lead-free module with a power dissipation of 43W. It is designed for through-hole mounting and is available in a rail/tube packaging with 8 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Onsemi FSAM10SM60A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Onsemi FSAM10SM60A technical specifications.
| Package/Case | Module |
| Collector Emitter Breakdown Voltage | 450V |
| Collector Emitter Saturation Voltage | 2.3V |
| Collector-emitter Voltage-Max | 600V |
| Current | 10A |
| Height | 7.5mm |
| Lead Free | Lead Free |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -20°C |
| Mount | Through Hole |
| Number of Outputs | 6 |
| Output Current | 10A |
| Output Voltage | 600V |
| Package Quantity | 8 |
| Packaging | Rail/Tube |
| Power Dissipation | 43W |
| RoHS Compliant | No |
| Series | SPM® |
| Voltage | 600V |
| RoHS | Not Compliant |
