Technical Specifications
Onsemi FUSB251UCX technical specifications.
General
| Max Operating Temperature | 85 |
| Number of Terminals | 15 |
| Min Operating Temperature | -40 |
| Terminal Position | BOTTOM |
| JEDEC Package Code | R-PBGA-B15 |
| Width | 1.49 |
| Length | 2.06 |
| Number of Functions | 1 |
| Temperature Grade | INDUSTRIAL |
| Supply Voltage-Nom (Vsup) | 3.8 |
| Supply Voltage-Max (Vsup) | 5.5 |
| Supply Voltage-Min (Vsup) | 2.7 |
| Number of Channels | 1 |
Compliance
| Lead Free | Yes |
| REACH | Compliant |
| Military Spec | False |
Datasheet
Onsemi FUSB251UCX Datasheet
Download the complete datasheet for Onsemi FUSB251UCX to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
