Differential Clock/Data Driver, 2:1:10 configuration, supporting data rates up to 6.125 Gbps and frequencies to 5.5 GHz. Features CML outputs, operating from 2.375V to 3.465V with a typical 2.5V supply. This surface mount component is housed in an 8x8mm QFN package, offering 10 outputs with a propagation delay of 0.39ns. It is RoHS compliant and halogen-free, supplied in a 260-piece tray.
Checking distributor stock and pricing after the page loads.
| Package/Case | QFN |
| Data Rate | 6.125Gbps |
| Frequency | 5.5GHz |
| Halogen Free | Halogen Free |
| Height | 1mm |
| Lead Free | Lead Free |
| Length | 8mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.465V |
| Min Supply Voltage | 2.375V |
| Mode of Operation | DIFFERENTIAL |
| Mount | Surface Mount |
| Number of Outputs | 10 |
| Operating Supply Current | 290mA |
| Operating Supply Voltage | 2.5V |
| Package Quantity | 260 |
| Packaging | Tray |
| Propagation Delay | 0.39ns |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Supply Current | 305mA |
| Turn-On Delay Time | 0.39ns |
| Width | 8mm |
| RoHS | Compliant |
These are design resources that include the Onsemi NB7L111MMNG
Onsemi product discontinuance notice PD22809X regarding parts affected by the IBM 5HP process closure. Last time buy date was March 4, 2020.
