The NB7N017MMNG is a single logic gate with a package type of QFN EP and a surface mount configuration. It operates at a nominal supply voltage of 3.465V and has a maximum operating frequency of 3.5GHz. The device is designed to function within a temperature range of -40°C to 85°C. It is compliant with RoHS regulations and is lead free. The gate is available in a tray packaging format with 260 units per package.
Checking distributor stock and pricing after the page loads.
| Package/Case | QFN EP |
| Depth | 8mm |
| Halogen Free | Halogen Free |
| Input | LVTTL |
| Lead Free | Lead Free |
| Length | 8mm |
| Max Frequency | 3.5GHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Package Quantity | 260 |
| Packaging | Tray |
| PLL | No |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | NB7N017M |
| Supply Voltage-Nom | 3.465V |
| Temperature Grade | INDUSTRIAL |
| RoHS | Compliant |
These are design resources that include the Onsemi NB7N017MMNG
Onsemi product discontinuance notice PD22809X regarding parts affected by the IBM 5HP process closure. Last time buy date was March 4, 2020.
