The NUP4012PMUTAG is a unidirectional TVS diode with a minimum breakdown voltage of 5.2V and a maximum reverse leakage current of 1uA. It operates over a temperature range of -40°C to 125°C and is suitable for surface mount applications. The device is RoHS compliant and available in a package quantity of 3000 units per reel. The NUP4012PMUTAG is part of the NUP4012PMU series and features a capacitance of 0.7pF.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Onsemi NUP4012PMUTAG datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Onsemi NUP4012PMUTAG technical specifications.
| Capacitance | 0.7pF |
| Direction | Unidirectional |
| Leakage Current | 1uA |
| Min Breakdown Voltage | 5.2V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Reverse Leakage Current | 1uA |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Operating Supply Voltage | 4V |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Polarity | Unidirectional |
| Reverse Breakdown Voltage | 5.2V |
| Reverse Standoff Voltage | 4V |
| RoHS Compliant | Yes |
| Series | NUP4012PMU |
| Termination | SMD/SMT |
| RoHS | Compliant |
