Technical Specifications
Onsemi SZBZX84C5V1LT3G technical specifications.
General
| Package/Case | SOT-23-3 |
| Halogen Free | Halogen Free |
| Impedance | 60R |
| Lead Free | Lead Free |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 225mW |
| Max Reverse Leakage Current | 2uA |
| Package Quantity | 10000 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q101 |
| Tolerance | 6% |
| Zener Voltage | 5.1V |
Compliance
| RoHS | Compliant |
Datasheet
Onsemi SZBZX84C5V1LT3G Datasheet
Download the complete datasheet for Onsemi SZBZX84C5V1LT3G to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
