The L7905CD2T is a single-output linear voltage regulator from Stmicroelectronics with a fixed output voltage of -5V and a maximum output current of 1.5A. It operates over a temperature range of 0°C to 150°C and is available in a D2PAK-3 package. The device is RoHS compliant and suitable for surface mount applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Stmicroelectronics L7905CD2T datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Stmicroelectronics L7905CD2T technical specifications.
| Package/Case | D2PAK |
| Dropout Voltage | 1.4V |
| Max Input Voltage | -35V |
| Min Input Voltage | -35V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 1.5A |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Regulators | 1 |
| Output Current | 1.5A |
| Output Type | Fixed |
| Output Voltage | -5V |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Polarity | Negative |
| Quiescent Current | 3mA |
| RoHS Compliant | Yes |
| Series | L7905C |
| RoHS | Compliant |
Download the complete datasheet for Stmicroelectronics L7905CD2T to view detailed technical specifications.
