Negative fixed output voltage regulator IC, providing a stable -5V output with a maximum output current of 1.5A. Features a 1.4V dropout voltage and a wide input voltage range from -7V to -35V. Housed in a TO-220 package for through-hole mounting, this lead-free component operates from 0°C to 150°C. Offers a Power Supply Rejection Ratio (PSRR) of 60dB and a quiescent current of 3mA.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Stmicroelectronics L7905CV datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Stmicroelectronics L7905CV technical specifications.
| Package/Case | TO-220 |
| Dropout Voltage | 1.4V |
| Height | 9.15mm |
| Lead Free | Lead Free |
| Length | 10.4mm |
| Max Input Voltage | -35V |
| Min Input Voltage | -7V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 1.5A |
| Min Output Voltage | -5V |
| Mount | Through Hole |
| Nominal Output Voltage | -5V |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Regulators | 1 |
| Output Configuration | Negative |
| Output Current | 1.5A |
| Output Type | Fixed |
| Output Voltage | -5V |
| Package Quantity | 1000 |
| Packaging | Rail/Tube |
| Polarity | Negative |
| Power Supply Rejection Ratio (PSRR) | 60dB |
| Quiescent Current | 3mA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Tolerance | 10% |
| Width | 4.6mm |
| RoHS | Compliant |
