Dual operational amplifier IC featuring a 1.1MHz bandwidth and 0.6V/µs slew rate. This general-purpose op-amp offers a 70dB common mode rejection ratio and 100dB voltage gain, with a low input bias current of 150nA. Designed for surface mounting in an SO package, it operates with a wide supply voltage range from 1.5V to 30V, consuming 700µA typical operating supply current. Ideal for applications requiring two independent amplifiers with low power consumption.
PackageSO
Current1.2mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Stmicroelectronics LM358D technical specifications.
General
Amplifier Type
GENERAL PURPOSE
Bandwidth
1.1MHz
Package/Case
SO
Common Mode Rejection Ratio
70dB
Dual Supply Voltage
9V
Gain Bandwidth Product
1.1MHz
Height
1.25mm
Input Bias Current
150nA
Input Offset Voltage (Vos)
7mV
Input Offset Voltage-Max
7mV
Lead Free
Lead Free
Length
4.9mm
Max Dual Supply Voltage
15V
Min Dual Supply Voltage
1.5V
Max Input Voltage
28.5V
Min Input Voltage
0V
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
30V
Min Supply Voltage
3V
Mount
Surface Mount
Number of Amplifiers
2
Number of Channels
2
Number of Circuits
2
Number of Elements
2
Operating Supply Current
700uA
Operating Supply Voltage
15V
Output Current
40mA
Output Current per Channel
60mA
Package Quantity
100
Packaging
Rail/Tube
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Slew Rate
0.6V/µs
Slew Rate-Nom
0.6V/µs
Supply Current
1.2mA
Technology
BIPOLAR
Unity Gain Bandwidth Product
1.1MHz
Voltage Gain
100dB
Width
3.9mm
Compliance
RoHS
Compliant
Datasheet
Stmicroelectronics LM358D Datasheet
Download the complete datasheet for Stmicroelectronics LM358D to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
